● Support IEI iRIS-2400 remote intelligent solution
● Intel® Celeron® J1900 quad-core SoC
● Robust IP65 aluminum front bezel
● Aesthetic ultra-thin bezel for seamless panel mount installation
● Projected capacitive multi-touch and resistive single touch options
● Dual full-size PCIe Mini card expansion
● 9V~36V DC wide range DC input

LCD 17'' (5:4)
Max Resolution 1280 (W) x 1024 (H)
Brightness (cd/m²) 350
Contrast Ratio 800 : 1
LCD Color 16.7M
Pixel Pitch (mm) (HxV) 0.26 x 0.26
Viewing Angle (V/H) 170° / 160°
Backlight MTBF (hrs) 50000
Touch Screen 5-wire resistive single-touch type flat touchscreen / 2-point projected capacitive type touchscreen
CPU Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
RAM 2 x 204-pin DDR3L SO-DIMM slot (max. 8GB), pre-installed with 2GB
I/O Ports and Switches 2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DCTerminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
Expansion Slot 1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot colay mSATA (SATA2 only) (with PCIe and USB signal)
Construction Material Aluminum front panel and sheet metal rear cover
Mounting Panel Mount/ Rack Mount/ 100 x 100 VESA Mount
Dimensions (WxHxD) (mm) 341.4 x 408.4 x 51.8
Cut Out Dimensions (WxH) (mm) 323 x 390
Net / Gross Weight 5kg
Operating Temperature -10°C~50°C (14°F~122°F)
Storage Temperature -20°C~60°C (-4°F~140°F)
Operating Humidity 10% to 95% (non-condensing)
IP Rating IP 65 compliant front panel
Safety & EMC CE & FCC Class A certified
Wireless LAN (optional) 802.11 a/b/g/n/ac + Bluetooth v4.0 wireless kit (SMA antenna)
Power Consumption 42W
PPC-F17B-BTi-J1/2G/R-R10 17” 350 cd/m² SXGA panel PC with Intel® Celeron® processor J1900, TDP 10W, one 2 GB RAM, support iRIS-2400, black color, 9-36V DC input, resistive touch window, R10
PPC-F17B-BTi-J1/2G/PC-R10 17” 350 cd/m² SXGA panel PC with Intel® Celeron® processor J1900, TDP 10W, one 2 GB RAM, support iRIS-2400, black color, 9-36V DC input, projected capacitive touch window, R10
