KINO-AH611 (Mini ITX)
Mini-ITX SBC with Socket G2 for Intel® mobile Core i7/ i5/ i3 CPU, VGA/Dual HDMI/LVDS, Dual PCIe GbE, USB 3.0, PCIe mini, SATA 6Gb/s and audio
- LGA1155 for the next generation Intel® Core™ i7/i5/i3/Pentium®/Celeron® processor supported
- Up to 16 GB 1333/1066 MHz dual-channel DDR3 SDRAM
- Support dual independent display by dual VGA and dual HDMI
- PCIe x16 slot and dual MiniPCIe card for high speed device expansion
- Two COM ports and three SATA 3Gb/s connectors supported
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery
| CPU | LGA1155 socket supports Intel® Core™ i7/i5/i3/Pentium®/Celeron® processor |
| System Chipset | Intel® H61 |
| BIOS | UEFI BIOS |
| System Memory | Two 204-pin 1066/1333 MHz dual-channel DDR3 SDRAM SO-DIMMs supported |
| Ethernet | Dual Realtek RTL8111E PCIe GbE controller with ASF 2.0 support |
| I/O Interface | 2 x RS-232 8 x USB 2.0 1 x TPM pin-header 3 x SATA 3Gb/s 1 x 6-pin header for PS/2 KB/MS |
| Digital I/O | Programmable 8-bit GPIO |
| Super I/O | Fintek F81866 |
| Audio | Realtek ALC662 HD Audio codec |
| Display Interfaces | Dual display supported 2 x VGA 2 x HDMI |
| Expansion | 1 x PCIe x16 slot 1 x Half-size PCIe Mini card slot |
| Watchdog Timer | Software programmable supports 1~255 sec. system reset |
| Power Supply | ATX Power Supply |
| Power Consumption | 5V@3.47A 12V@0.11A Vcore_12V@6.73A 3.3V@1.01A 5VSB@0.15A (3.4GHz Intel® Core™ i7-2600K with two 1333 MHz 2 GB DDR3 SO-DIMMs) |
| Graphic | Support for DX10.1 and OpenGL3.0, full MPEG2. VC1. AVC decode |
| Temperature | Operating: -10°C ~ 60°C |
| Humidity | Operating: 5% ~95%, non-condensing |
| Dimensions | 170mm x 170mm |
| Weight | GW:1100g, NW: 700g |
| Embedded Controller | iWDD |
| Fan Connector | 1 x 4-pin CPU fan connector 1 x 3-pin system fan connector |
| KINO-AH611-R10 | Mini-ITX SBC supports LGA1155 Intel® Core™ i7/i5/i3/ Pentium®/Celeron® CPU, DDR3, dual HDMI/dual VGA, dual PCIe GbE, SATA 3Gb/s, HD Audio and RoHS |
| ACCESSORIES | |
| 19800-003100-300-RS | Dual port USB cable with bracket |
| 32102-000100-100-RS | SATA power cable |
| TPM-IN01-R11 | 20-pin Infineon TPM module, software management tool, firmware V3.17 |
| SACF-KIT01-R10 | SATA to CF converter board |
| 32006-001100-100-RS | KB/MS Y cable |
| CF-1156A-RS-R11 | High-performance LGA1155/LGA1156 cooler kit, 1U chassis compatible, 73W |
| CF-1156E-R11 | High-performance LGA1155/LGA1156 cooler kit, 95W |
| CF-1156C-RS | LGA1155/LGA1156 cooler kit, 1U chassis compatible, 45W |
| CF-1156D-RS | LGA1155/LGA1156 cooler kit, 1U chassis compatible, 65W |
