IMBA-G410
ATX motherboard supports 32nm LGA1155 Intel® Xeon® E3/Core™ i3/Celeron® CPU per Intel® C206, DDR3, VGA/DVI/HDMI, Dual Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, Audio and RoHS
- Support Intel® Core™2 Quad/ Core™2 Duo/ Pentium®4/ Celeron® processor
- Dual channel DDR3 1066MHz supports up to 8GB
- Intel® GMA X4500 delivers an excellent blend of graphics performance
- TPM V1.2 hardware security function supported by TPM module
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery
| CPU | LGA775 45nm Intel® Core™2 Quad, Core™2 Duo, Pentium® D, Celeron® at FSB 800/1066/1333MHz processors |
| System Chipset | Intel® G41+ICH7 |
| BIOS | AMI BIOS |
| System Memory | Two 240-pin 4GB (max.) 800/1066MHz dual-channel DDR3 SDRAM DIMM supported (System max. 8GB) |
| Ethernet | Dual Realtek RTL8111E PCIe GbE controllers,LAN 1 with ASF2.0 support |
| I/O | 5 x RS-232 1 x RS-232/422/485 with Auto Flow control 1 x LPT 1 x IDE 2 x PS/2 KB/MS 4 x SATA II 1 x CF Type II slot |
| Digital I/O | 8-bit digital I/O 4-bit input / 4-bit output |
| Super I/O | Fintek F81865 |
| Infrared | 1 x 5-pin header |
| TPM | 2 x10-pin header |
| Audio | Realtek ALC888 HD audio codec |
| Display Interfaces | Intel® GMA X4500 Supports DirectX 10 / OpenGL 1.5 VGA display supports analog CRT up to 2048x 1536 @ 75MHz |
| Audio | Software programable 1-255 sec. by super I/O |
| Expansion | 1 x PCIe x16 slot (support PCIe x1/x16 PCIe add-on card and SDVO card) 1 x PCIex4 slot (with x1 signal) 5 x PCI Slot |
| Power Supply | ATX power supply |
| Fan | 1 x 4-pin CPU fan connector 3 x 3-pin system fan connector |
| Power Consumption | 12V@4.80A, -12V@0.06A, 5V@5.45A, 3.3V@0.16A (Intel® Q9550 2.83GHz with 2GB 1333MHz DDR3 Memory) |
| Temperature | Operation: -10°C ~ 60°C |
| Humidity | Operation: 5% ~ 95%, non-condensing |
| Dimensions | 244mm x 305mm |
| Weight | GW:1200g / NW: 650g |
| IMBA-G410-R20 | ATX Motherboard supports Intel LGA775 Core 2 Duo/Quad with FSB 800/1066/1333MHz processor include VGA, PCIe x16, PCIe x4(x1 signal), PCI, Dual PCIe GbE, USB 2.0, COM, CF, SATA II and Audio, RoHs,R20 |
| ACCESSORIES | |
| 32225-002000-100-RS | IDE cable |
| 32102-000100-100-RS | SATA power cable |
| 19800-000100-200-RS | Quad ports USB cable with bracket |
| 19800-003100-300-RS | Dual ports USB cable with bracket |
| 19800-004400-100-RS | RS-232/422/485 cable |
| CF-775A-RS | CPU cooler for 130W |
| CF-520-RS-R11 | CPU cooler for 115W |
| CF-775B-RS-R11 | 1U CPU cooler for 90W |
| SDVO-100DVI-R10 | PCIe x16 DVI Output SDVO card supports dual display (IEI CPU board only) |
| SDVO-100VGA-R10 | PCIe x16 VGA Output SDVO card supports dual display (IEI CPU board only) |
| TPM-IN01-R11 | 20-Pin Infineon TPM module, software management tool, firmware V3.17 |
