IGCME-1300 (Add On Card)
IPMI 2.0 adapter card with AST2400 BMC chip for DDR3 SO-DIMM socket interface
- Compliant with PCI Express Mini specification 1.2
- Compatible with KINO-QM670-R10 & PCIE-Q670-R10
- Support PCIe VGA/2D Controller, 1920x1200@60Hz 32bpp
- DDR3 SDRAM supports up to 800 MHz speed
| Form Factor | PCI Express Mini card |
| Display Controller | Aspeed AST1400 |
| Internal Connector | 1 x 10-pin (2x5) box header by 2.0mm pitch |
| Compatible OS | Windows® 2000/XP/Server 2003/Server 2008 Linux kernel version 2.6.32 above |
| Power Supply | On-board 3.3V |
| Operating Humidity | 5% ~ 95%, non-condensing |
| Operating Temperature | -10°C ~ 60°C |
| Dimensions (LxW) | 50mm x 30mm |
| Weight | 70g |
| IGCME-1300-R11 | PCIe Mini VGA adapter card, RoHs |
