ICE-CV-N26002
COM Express Rev 2.0 Basic/Compact Type II Module,Intel® Atom™ D2550 Processor,VGA/LVDS, PCI, GbE, SATAII, USB and Audio, RoHS
- COM Express Type II Basic (Computer-On-Module) form factor for flexible base board design
- Intel® Atom™ N2600 dual-core processor 1.6 GHz/512 x 2 L2 cache
- Support DDR3 & DDR3L (1.35V) 1066/800MHz, up to 2GB
- 1 x single channel LVDS 18-bit
| Form Factor | PICMG COM Express R2.0 Type II for Compact size 95 mm x 95 mm 10-layers |
| CPU | Intel® Atom™ N2600 dual-core processor 1.6 GHz/512 x 2 L2 cache |
| PCH | Intel® NM10 |
| Memory | Support DDR3 & DDR3L (1.35V) 1066/800MHz, up to 2GB |
| BIOS | UEFI |
| Display Output | VGA Integrated in the Intel® N2600 signal to base board 1 x CRT 1 x single channel LVDS 18-bit |
| Ethernet | RTL8111E-VL-CG Gbe Ethernet Co- lay RTL8111E-VB-GR |
| Embedded Controller | iWDD (ITE) |
| USB | 8 x USB 2.0 signal to base board |
| SATA | 2 x SATA 3GB/s signal to base board |
| Audio | High definition audio interface to base board |
| GPIO | Yes, to Base Board |
| SMBus | Yes,to Base Board |
| I2C | Yes, to Base Board |
| PCI | Yes, to Base Board |
| LPC | Yes, to Base Board |
| SPI | Yes, to Base Board |
| Serial Ports | 2 Serial to Base Board |
| Expansion | 3 x PCIe x1 signal to base board |
| PCI | Yes, to Base Board |
| Watchdog Timer | Software programmable support 1~255 sec. system reset (by EC) |
| Power Consumption | +12V@0.45A, Vcore _12V@1.0A |
| Operating Temperature | -10°C ~ 60°C |
| Operating Humidity | 5% ~95%, non-condensing |
| Dimensions | 95 mm x 95 mm |
| Weight | GW: 600g / NW: 200g |
| ICE-CV-N26002-R10 | COM Express Rev 2.0 Basic/Compact Type II Module Intel® Atom™ N2600 Processor, VGA/LVDS, PCI, GbE, SATAII, USB and Audio, RoHS |
| ICE-CV-N28002-R10 | COM Express Rev 2.0 Basic/Compact Type II Module Intel® Atom™ N2800 Processor, VGA/LVDS, PCI, GbE, SATAII, USB and Audio, RoHS (by project support, MOQ 100pcs / lot) |
| ICE-DB-9S-R10 | Baseboard for COM Express Type II modules |
