AFL-10A-N270 (Fanless All In One Panel PC)
- 10.4” TFT LCD with resistive touch screen
- Intel® Atom™ N270 1.6GHz CPU
- Selectable AT/ATX power mode through the switch on the chassis inside
- Fanless cooling system
- System memory up to 2 GB SDRAM
- Built-in HSUPA module for mobile connection (Optional)
- One compact flash slot
- IP 64 compliant front panel
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery
| LCD Size | 10.4” |
| Max Resolution | 800 x 600 |
| Brightness (cd/m²) | 400 |
| Contrast Ratio | 700:1 |
| LCD Color | 262K |
| Pixel Pitch (mm) | 0.264 (H) x 0.264 (V) |
| Viewing Angle (H-V) | 160º/140º |
| Backlight MTBF | 50000 hrs |
| SBC Model | AFLMB-945GSE-N270-R10 |
| CPU | Intel® Atom™ N270 1.6GHz CPU |
| Chipset | Intel 945GSE / ICH7M |
| Memory | Supports one 400MHz or 533MHz DDRII SO-DIMM (2GB Max.) |
| I/O Ports | 1 x RS232 COM Port 1 x RS-232/422/485 COM port 2 x RJ-45 for Giga LAN 2 x USB 2.0 1 x Power Switch 1 x Reset Button 1 x External SATA 1 x Audio Port 1 x Power Jack |
| SSD | CF TypeII |
| Watchdog Timer | Software Programmable supports 1~255 sec. Syetem Reset |
| Audio | AMP 1.5W + AMP 1.5W (internal speaker) |
| Wireless | 1 x Wireless Lan 802.11 b/g Module (internal PCIe mini card interface) Optional AFL-BT-KIT02-R10 Bluetooth Module Kit |
| Drive Bay | N/A |
| Optional HSUPA Module (support GSM 850, EGSM 900, DCS 1800 & 1900) | 1 x HSUPA Mobile Module (internal USB Interface) |
| Construction Front Panel | ABS + PC Plastic front frame |
| LED Function | 1 x LED on Front Panel for Power ON/OFF |
| Mounting | Panel, Wall, Rack, Stand and Arm VESA 75mm x 75mm / 100mm x 100mm |
| Front Panel Color | Gray 7539U |
| Dimension (WxHxD) (mm) | 276 x 227 x 50.7 |
| Operation Temperature | -10°C ~50°C |
| Storage Temperature | -20°C ~ 60°C |
| Net Weight | 1.4 Kg |
| IP Level | Front Frame IP64 |
| Safety & EMC | Meets CE / FCC / CB / CCC |
| Touch Screen | Resistive Type 4-Wire (Touch controller IC is on board) |
| Power Adapter | P/N: 63040-010060-130-RS 60W Power Adapter (Meet PSE) Input: 90VAC~264VAC, 50/60Hz Output: 12VDC |
| Power Requirement | 12VDC |
| Power Consumption | 28W |
| EOL Issued for AFLx-BT-KITxx, See AFLx-BT-KITxx Series EOL for Details | |
| AFL-10A-N270/R/1G-R24 | 10.4” 400cd/m² SVGA fanless panel PC with Intel® Atom™ N270 1.6GHz,802.11b/g/n wireless module, Touch Screen ,1GB DDR2 533,R24 |
| NOTE: | Order HSUPA02 for HSUPA Function |
| ACCESSORIES | |
| AFLWK-12 | Wall Mount Kit |
| AFLPK-12 | Panel mounting kit |
| AFLRK-10 | Rack mounting kit |
| VSTAND-A10 | VESA Standard multi-mounting stand, allows 0° to 90° adjustable Wall/Ceiling/Desk/Rear/Side mounting, heat dissipation holes, compact size provides mobility, RoHS |
| STAND-A12 | 10"-12.1" VESA 100x100mm PPC/monitor stand, supports up to 5KG. silver color, RoHS |
| STAND-100-RS | LCD Monitor Stand, support 3 ~ 8kg , white, forward and backward tilt, heavy duty steel, 75/100 VESA |
| STAND-150-RS | LCD Monitor Stand, support up to 9kg, VESA 75/VESA 100(optional), tilt and vertical adjustment, RoHS |
| ARM-11-RS | Flat Panel Monitor Arm, VESA 75/100, 3kg~6kg; RoHS |
| ARM-31-RS | Flat Panel Monitor Arm, VESA 75/100, 7kg~14kg; RoHS |
| IDD-930160-KIT | 60W DC/DC 9-30 VDC input vehicle power adapter for AFOLUX Panel PC and Monitor |
| AFLP-12BMSR-U-R11 | Magnetic Stripe Reader |
| AFL-BT-KIT02-R10 | Bluetooth Kit Module |
| AUPS-A10-R10 | DC 12V Input UPS |
| AUPS-A20-R10 | DC 9-36V Input UPS |
| AFLCF-10-N270-XPE-R24 | OS: WIN XP Embedded with 1GB Compact flash card, and Thin Client software package |
| AFLCF-10-N270-WES7E-R24 | OS: Windows7 Embedded (2 GB CF card) |
